Corrosion-Resistant Zirconium Tubes – Shaanxi Peakrise Metal Co., Ltd.

Product Introduction

Shaanxi Peakrise Metal Co., Ltd. is a trusted manufacturer and global supplier of corrosion-resistant zirconium tubes. Zirconium, known for its excellent corrosion resistance, is highly valued in industries like chemical processing, power generation, and nuclear energy. Our zirconium tubes are produced using advanced manufacturing processes, ensuring that they meet the highest industry standards for durability, performance, and reliability. As a supplier of corrosion-resistant zirconium tubes, we prioritize delivering top-quality products that help customers achieve superior performance in harsh environments.

Zirconium’s ability to resist corrosion, especially in acidic environments, makes it ideal for industries where materials are frequently exposed to chemicals and extreme conditions. Our corrosion-resistant zirconium tubes are specifically designed to withstand these challenges, offering longevity and stability. Shaanxi Peakrise Metal Co., Ltd. has a solid reputation for producing high-purity zirconium products, ensuring that our tubes are free from impurities that could compromise their performance. With over a decade of experience in exporting high-quality non-ferrous metals, including zirconium, we are dedicated to meeting the diverse needs of industries around the world.

Our zirconium tubes are used in applications where resistance to aggressive chemicals is critical. These include the chemical processing industry, petrochemical industry, and even the nuclear sector, where zirconium’s low neutron-capture cross-section is highly beneficial. Whether your project requires tubes for heat exchangers, pipelines, or pressure vessels, Shaanxi Peakrise Metal Co., Ltd. has the expertise and capacity to deliver top-tier solutions.

Product Specifications

Name:	Corrosion-Resistant Zirconium Tubes
Grade:	Zr2 Zr4 Zr702 Zr705 Zr60804 Zr60001 Zr60901
Density:	6.51g/cm³
Size:	OD 6-300mm,WT 0.5-10mm,L <20meters Or process according to customer's request.
Standard:	ASTM B523 ASTM B658,ASTM B353
Main process:	Preparation of consumable electrodes, casting, forging, hot extrusion (tube blank), cold working and finishing.
Status:	Annealing (M) Hot working status (R) Cold working status (Y) Annealing
Surface:	Rolled surface, polished surface, polished surface, pickled metal surface

Parameter	Value
Outer Diameter (OD)	8mm - 80mm
Wall Thickness	0.8mm - 6mm
Length	Up to 4000mm
Zirconium Purity	≥ 99.6%
Tensile Strength	≥ 340 MPa
Yield Strength	≥ 210 MPa
Elongation	≥ 18%
Hardness (HV)	100 - 130

Physical and Chemical Properties

Zirconium has unique properties that make it highly suitable for corrosion-resistant applications:

High Corrosion Resistance: Especially against strong acids and alkalis.
Low Neutron-Capture Cross-Section: Making it suitable for nuclear applications.
High Melting Point: 1855°C, allowing it to perform well at high temperatures.
Excellent Ductility and Strength: Provides the necessary mechanical properties for various industrial applications.
Non-Magnetic: Ideal for sensitive electronic applications.

Grade	Element composition(%)<									Standard
Grade	Zr+Hf	Hf	Fe+Cr	Sn	H	N	C	Nb	O	Standard
R60702	99.2	4.5	0.20	--	0.005	0.025	0.05	--	0.16	ASTM B658
R60703	98	4.5	--	--	--0.005	0.025	--	--	--
R60704	97.5	4.5	0.20~0.40	1.0~2.0	0.005	0.025	0.05	--	0.18
R60705	95.5	4.5	0.2	--	0.005	0.025	0.05	2.0~3.0	0.18
R60706	95.5	4.5	0.2	--	0.005	0.025	0.05	2.0~3.0	0.18
R60804	97.5	0.01	0.25~0.37	1.2~1.7	0.0025	0.008	0.027	--	0.09~0.16	ASTM B353
R60001	99.9	0.01	0.17	0.005	0.0025	0.008	0.027	--	--	ASTM B353

Product Functions

Corrosion Resistance: Zirconium tubes provide excellent protection against corrosive environments, making them ideal for applications in chemical processing, oil refining, and more.
Heat Resistance: With its high melting point, zirconium is suitable for high-temperature applications, ensuring reliable performance under extreme heat.
Nuclear Applications: Zirconium’s low neutron-capture cross-section makes it a critical material for use in nuclear reactors and fuel rod cladding.
Longevity: The durability of zirconium tubes ensures long-term performance, reducing the need for frequent replacements and maintenance.
Biocompatibility: Zirconium’s non-toxic and non-reactive nature allows it to be used in medical devices and implants.

Manufacturing Process

Our corrosion-resistant zirconium tubes are produced through a highly controlled process to ensure superior quality:

Melting and Alloying: High-purity zirconium is melted in a vacuum arc furnace to remove impurities and create the base material.
Extrusion: The material is extruded into tubes using high-pressure extrusion machines to achieve precise dimensions.
Annealing: The tubes are heat-treated to improve ductility and relieve internal stresses.
Cold Working: Through rolling and drawing processes, the tubes are cold worked to achieve the desired size and mechanical properties.
Final Inspection: Each tube undergoes stringent testing to ensure it meets the required standards for strength, corrosion resistance, and dimensions.

Our Quality Inspection

Why Choose Shaanxi Peakrise Metal Co., Ltd.?

Extensive Experience: With over a decade in the non-ferrous metal industry, we have become a trusted supplier for clients across multiple industries.
Advanced Equipment: Our state-of-the-art production facility ensures high-quality output, with equipment such as vacuum arc melting furnaces, plasma welding rooms, and CNC machines.
Global Reach: Our products are exported to over 10 countries, including the United States, Germany, South Korea, and Australia.
High-Quality Standards: We adhere to strict quality control measures, ensuring that every product meets the highest standards of purity and performance.
Custom Solutions: We offer OEM/ODM services, tailoring our products to meet your specific needs.

OEM Services

Shaanxi Peakrise Metal Co., Ltd. supports full OEM/ODM services, including custom tube dimensions, finishes, and packaging. We work closely with our clients to develop solutions that fit their unique requirements, ensuring high satisfaction and project success.

molybdenum electrodes glass melting workshop

molybdenum electrodes glass melting workshop 2

Packaging

Wooden Crate Packaging: Ensures safe transportation of heavy or bulky goods.
Carton Packaging: Lightweight packaging for smaller products.
Foam Inserts: Protect the product from physical damage during transportation.
Waterproof Packaging: Prevents moisture damage during transit.
Custom Packaging: Available for unique customer requirements.
International Standard Packaging: Meets all global shipping regulations for safe delivery.

Logistics

Sea Freight: Ideal for bulk orders and cost-effective shipping.
Air Freight: Fast delivery for urgent orders.
Land Transportation: Efficient and flexible for domestic shipments.
Multimodal Transport: Combining different transport methods for optimal delivery.
Courier Services: For smaller, time-sensitive deliveries.

FAQ

What industries use zirconium tubes?
Zirconium tubes are widely used in the chemical processing, nuclear, oil and gas, and power generation industries.
Can I customize the size of the zirconium tubes?
Yes, we offer fully customizable dimensions to meet your specific project requirements.
How do you ensure the quality of your zirconium tubes?
We follow strict quality control procedures, including chemical composition analysis and mechanical testing, to ensure top-quality products.
What is the delivery time for orders?
Delivery times depend on the order size and destination but typically range from 2-6 weeks.
Do you offer OEM services?
Yes, we provide full OEM services, allowing you to customize the size, shape, and packaging of our zirconium tubes.

Call to Action (CTA)

Contact Us
Ready to experience the high-quality performance of corrosion-resistant zirconium tubes? Shaanxi Peakrise Metal Co., Ltd. is here to meet your needs. Whether you're looking for standard products or custom solutions, we are dedicated to providing top-tier service. Get in touch today to discuss your project requirements at info@peakrisemetal.com! We look forward to collaborating with you.
