Zirconium Foil Sheets for Fabrication
Model Number：Custom
Minimum Order Quantity：1pc
Price:Negotiate
Packaging Details:Plywood case
Delivery Time:5~7days
Payment Terms:T/T
Supply Ability:50ton/month
PRODUCT DESCRIPTION
Zirconium Foil Sheets for Fabrication - High-Quality Solutions by Shaanxi Peakrise Metal Co., Ltd.
Product Introduction
Zirconium is a unique metal known for its exceptional resistance to corrosion and high-temperature stability, making it indispensable in industries such as aerospace, chemical processing, and nuclear power generation. Zirconium Foil Sheets are essential for fabricating components that must endure extreme conditions. Whether it's used in heat exchangers, nuclear reactors, or in the creation of specialized chemical equipment, Zirconium's properties provide unmatched performance and durability.
At Shaanxi Peakrise Metal Co., Ltd., we specialize in the production and supply of high-quality Zirconium Foil Sheets for fabrication. As a trusted manufacturer in the non-ferrous metal industry, we are committed to delivering products that meet the stringent demands of our global clientele. With decades of experience and a focus on international trade since 2010, we have established ourselves as a leading supplier in the field. Our Zirconium Foil Sheets are manufactured with precision, adhering to international standards, ensuring consistent quality and performance.
Our Zirconium Foil Sheets offer superior resistance to corrosive environments, making them ideal for industries where protection against chemical attack is crucial. We understand that every project has unique requirements, and that’s why we offer customization services to match your specific needs, whether it's in size, thickness, or application-specific properties.
Product Specifications
The following table outlines the standard dimensions and material properties of our Zirconium Foil Sheets. If you require specific customizations, we are more than happy to assist.
| Product Name | Zirconium Strip/ Zirconium Foil |  |
| Grade | Zr2 Zr4 Zr702 Zr705 Zr60001 Zr60804 Zr60901 | |
| Purity | >99.7% | |
| Width | <600mm | |
| Thickness | min.0.01mm | |
| Surface | Bright | |
| Process | Cold rolled | |
| Standard | ASTM B551 ASTM B352 | |
| Shape | Coil or Flat | |
| Delivery status | Annealed | |
| Cutom size | Yes, can accept OEM |
| Grade | Element composition(%)< | Standard | ||||||||
| Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | Nb | O | ||
| R60702 | 99.2 | 4.5 | 0.20 | -- | 0.005 | 0.025 | 0.05 | -- | 0.16 | ASTM B551 |
| R60703 | 98 | 4.5 | -- | -- | --0.005 | 0.025 | -- | -- | -- | |
| R60704 | 97.5 | 4.5 | 0.20~0.40 | 1.0~2.0 | 0.005 | 0.025 | 0.05 | -- | 0.18 | |
| R60705 | 95.5 | 4.5 | 0.2 | -- | 0.005 | 0.025 | 0.05 | 2.0~3.0 | 0.18 | |
| R60706 | 95.5 | 4.5 | 0.2 | -- | 0.005 | 0.025 | 0.05 | 2.0~3.0 | 0.18 | |
Physicochemical Properties
Zirconium is prized for its remarkable physicochemical properties, including:
- Corrosion Resistance: Highly resistant to most acids and alkalis, making it suitable for use in harsh environments.
- High Melting Point: With a melting point of 1855°C, Zirconium performs exceptionally well in high-temperature applications.
- Low Neutron Absorption: This property makes Zirconium ideal for use in nuclear reactors, where minimal neutron absorption is critical.
- Ductility: Zirconium is malleable and ductile, allowing it to be easily shaped into thin sheets without compromising its structural integrity.
| Standard | Grade | Status | Rm(≥)/MPa | Rp0.2(≥)/MPa | A51mm(≥)/% |
| ASTM B551 Zr sheet/strip thickness ≤25mm |
R60702 R60704 R60705 R60706 |
Annealed |
379 413 552 510 |
207 241 379 345 |
16 14 16 20 |
| ASTM B658 Zr seamless tube/welding pipe |
R60702 R60704 R60705 |
Annealed |
379 413 552 |
207 241 379 |
16 14 16 |
| ASTM B523 Zr seamless & welding heat exchange tube |
R60702 R60704 R60705 |
Annealed |
379 413 552 |
207 241 379 |
16 14 16 |
| ASTM B550 Zr rod/wire |
R60702 R60704 R60705 |
Annealed |
379 413 552 |
207 241 379 |
16 14 16 |
| ASTM B493 Zr Forging |
R60702 R60704 R60705 |
Annealed |
379 413 483 |
207 241 379 |
16 14 16 |
Product Applications
Zirconium Foil Sheets are widely used across various industries due to their exceptional properties. Some of the most common applications include:
- Nuclear Industry: Used in fuel rod claddings and reactor components due to its low neutron absorption and high resistance to radiation damage.
- Aerospace Industry: Provides high-temperature stability and corrosion resistance, making it suitable for components in jet engines and spacecraft.
- Chemical Processing: Essential for equipment in chemical plants, such as heat exchangers, reaction vessels, and pipes, where protection from corrosive substances is necessary.
- Medical Devices: Used in medical implants and devices due to its biocompatibility and resistance to body fluids.
- Electronic Devices: Applied in semiconductor industries where Zirconium’s conductive properties and high purity are crucial.
Production Process & Manufacturing Workflow
Our manufacturing process ensures high-quality production through advanced technologies and strict quality control measures:
- Raw Material Selection: We source high-purity Zirconium to guarantee the final product's quality.
- Melting: The material is melted in vacuum arc furnaces to ensure purity and eliminate contaminants.
- Rolling: The molten Zirconium is then rolled into thin sheets with precise thickness controls.
- Annealing: To enhance ductility, the sheets are annealed in a vacuum furnace, preventing oxidation and improving their workability.
- Quality Testing: Each batch undergoes rigorous testing for tensile strength, thickness, and surface finish to meet international standards.
Why Choose Us?
Here’s why Shaanxi Peakrise Metal Co., Ltd. is the ideal partner for your Zirconium Foil Sheet needs:
- Rich Industry Experience: With over a decade of exporting non-ferrous metals, we understand the needs of global customers.
- Advanced Equipment: Our factory is equipped with state-of-the-art machinery, including vacuum furnaces, rolling mills, and CNC machines.
- Customization Services: We offer OEM/ODM services to meet your unique product specifications.
- Quality Assurance: Each product undergoes rigorous testing to ensure it meets both industry standards and customer expectations.
- Global Reach: We have successfully partnered with clients in the US, Europe, Asia, and beyond, earning a reputation for quality and reliability.
FAQ
-
What is the purity level of your Zirconium Foil Sheets?
Our sheets boast a minimum purity of 99.95%, ensuring high performance in even the most demanding applications. -
Can I order custom dimensions?
Yes, we offer full customization services, including non-standard sizes and thicknesses. -
What are the typical lead times for orders?
Lead times vary depending on the order size and customization needs, but we strive to deliver within 3 to 5 weeks. -
Do you offer sample sheets for testing?
Yes, we provide sample sheets upon request for evaluation before large-scale production. -
How are the products packaged for shipment?
All products are packaged to meet international shipping standards, ensuring safe and damage-free delivery.
Packaging
We take packaging seriously to ensure the safe and secure delivery of your products:
- Wooden Crate Packaging: Sturdy wooden crates provide protection during long-distance shipping.
- Carton Packaging: Smaller quantities are securely packaged in durable cardboard boxes.
- Foam Cushioning: Foam inserts are used to prevent movement and absorb shocks during transit.
- Waterproof Packaging: All shipments are wrapped in waterproof materials to protect against moisture and humidity.
- Customized Packaging: Tailored packaging solutions are available based on your specific requirements.
Logistics
We offer a range of shipping options to meet your logistical needs:
- Sea Freight: Cost-effective option for large-volume orders.
- Air Freight: Expedited shipping for urgent orders.
- Land Freight: Efficient overland transportation within certain regions.
- Multimodal Transport: Combining air, sea, and land freight for optimized logistics.
- Courier Services: Fast, trackable delivery for smaller shipments.
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Contact Us
Ready to take your next project to the next level? Contact Shaanxi Peakrise Metal Co., Ltd. today for high-quality Zirconium Foil Sheets tailored to your specific needs. Our expert team is here to provide assistance, answer questions, and guide you through the process. Let’s work together to bring your vision to life.
Reach out at: info@peakrisemetal.com
We look forward to hearing from you!
